Connectors UTS được HDH phân phối chính hãng tại Việt Nam.
The industrial SOURIAU UTS series with bayonet coupling and extreme sealing performances is available in 5 shell sizes and 30 insert arrangements. A hi-seal SOURIAU UTS version is available offering extreme sealing performance in unmated and mated conditions and compatible with MIL-DTL-26482.
- Full Plastic connector
- 250 mating cycle
- 1/3-turn-bayonet coupling
- UL / IEC qualified
- Interchangeable / Intermateable with UTG & UTO series*
- High resistance to UV and corrosion
- IP68 / IP69K sealing even in dynamic situations
MECHANICAL
| Industrial/Commercial | x |
| Harsh Environment | x |
| Military | |
| Wire Gauge Range (AWG) |
30 to 8 |
| Number of Circuits |
2 to 32 |
| Sealed Against Water Jets | Available |
| EMI / RFI Shielding | No |
| Style | Circular |
| Operating Voltage | 650 VAC |
| Current Rating (Amps) | 44 |
| Power & Signal on Same Layout | Available |
| Operating Temperature |
-40°F to 221°F -40°C to 105°C |
| Submersible |
Available |
| Individual Wire Sealing | Available |
| Cable Jacket Sealing |
Available |
| Type of Coupling | Bayonet |
| Life in Mating Cycles (min.) | 250 |
| Shock Test (g’s) | – |
| Vibration Test (grms) | – |
| Susceptibility to Damage | Low |
| Shell Material | Thermoplastic |
| Shell Plating |
None |
| Shell Color |
Black |
| Positive Shell Polarization | Available |
| Insert Polarization Options | No |
| User Polarization | No |
| Standards/Associated Specs. |
UL, IEC |
| Contact Plating | Gold, Tin, or Silver |
| Contact Styles | Pin / Socket |
| Crimp | x |
| Solder | x |
| Printed Circuit Solder | x |
| Printed Circuit Press Fit | |
| Thermocouple | |
| Wire Wrap | |
| Co-ax | x |
| Insulation Displacement or Screw | x |
| Pre-Terminated | x |
| Fiber Optic | x |
| High Voltage | |
| First-Mate Last-Break | x |
