Connectors MARC được HDH phân phối chính hãng tại Việt Nam.
The Anderson Power Products Multi Axial Rotational Connector “MARC” features 8 Powerpole® circuits integrated into a blindmate housing. The connector is designed to blindmate from 2 rotating axis or straight on. The two row, horizontally oriented connector uses industry leading flat wiping contacts. The MARC connector series is rated to 29 amps per circuit and can be configured with 8 standard length contacts or 6 standard length and 2 pre-mate, multi-purpose contacts, which can function as ground, power or signal. The rugged connector is UL listed and rated up to 10,000 mating cycles. The dielectric is a chemically resistant PBT plastic.
FEATURES
- Rotational blindmate error correction
- Sequential mating
- Mechanically keyed housing
- Rugged and durable
- Interchangeable genderless design
MECHANICAL
| Industrial/Commercial | x |
| Harsh Environment | |
| Military | |
| Wire Gauge Range (AWG) |
20 to 10 |
| Number of Circuits |
1 to 8 |
| Sealed Against Water Jets | No |
| EMI / RFI Shielding | No |
| Style | Rectangular Blindmate |
| Operating Voltage |
600 VAC / DC |
| Current Rating (Amps) |
29 |
| Power & Signal on Same Layout | No |
| Operating Temperature |
-40°F to 257°F -40°C to 125°C |
| Submersible |
No |
| Individual Wire Sealing | No |
| Cable Jacket Sealing |
No |
| Type of Coupling | Quick Disconnect |
| Life in Mating Cycles (min.) | 10,000 |
| Shock Test (g’s) | – |
| Vibration Test (grms) | – |
| Susceptibility to Damage | Low |
| Shell Material |
PBT |
| Shell Plating |
– |
| Shell Color |
Black |
| Positive Shell Polarization | Available |
| Insert Polarization Options | No |
| User Polarization | No |
| Standards/Associated Specs. |
UL, CSA |
| Contact Plating | Silver or Tin |
| Contact Styles | Flat-Wiping |
| Crimp | x |
| Solder | |
| Printed Circuit Solder | |
| Printed Circuit Press Fit | |
| Thermocouple | |
| Wire Wrap | |
| Co-ax | |
| Insulation Displacement or Screw | |
| Pre-Terminated | |
| Fiber Optic | |
| High Voltage | |
| First-Mate Last-Break | x |
