Connectors E-SERIES được HDH phân phối chính hãng tại Việt Nam.
LEMO E-Series IP68 connectors are used in military applications, medical devices, oil and gas applications, public sector, industrial control and test & measurement environments. All models of this Series are waterproof and watertight when mated and correctly assembled to an appropriate cable to give a protection index of IP68 as per IEC 60529 standard (IP66 in unmated condition). Self-latching IP68 connectors with stepped inserts for alignment (of multipole version) and rugged housing for extreme working conditions.
FEATURES
- Push-Pull self-latching for secure connections
- 7 sizes / 22 shell styles
- Stepped inserts for blind mating
- Temp. range -55°C to 200°C
- Solder or print contacts
- Shielding: >95dB at 10Mhz / >80dB at 1GHz
- UL listed
MECHANICAL
| Industrial/Commercial | x |
| Harsh Environment | x |
| Military | |
| Wire Gauge Range (AWG) |
48 to 0 |
| Number of Circuits | 1 to 106 |
| Sealed Against Water Jets | Available |
| EMI / RFI Shielding | Available |
| Style | Circular |
| Operating Voltage | 3000 VAC |
| Current Rating (Amps) | 230 |
| Power & Signal on Same Layout | Available |
| Operating Temperature |
-67°F to 392°F -55°C to 200°C |
| Submersible |
Available |
| Individual Wire Sealing | No |
| Cable Jacket Sealing |
Available |
| Type of Coupling | Push-Pull |
| Life in Mating Cycles (min.) | 5000 |
| Shock Test (g’s) | 100 |
| Vibration Test (grms) | 15 |
| Susceptibility to Damage | Low |
| Shell Material | Brass or Stainless Steel |
| Shell Plating |
Chrome or Anodize |
| Shell Color |
Silver or Black |
| Positive Shell Polarization | Available |
| Insert Polarization Options | Available |
| User Polarization | No |
| Standards/Associated Specs. |
– |
| Contact Plating | Gold |
| Contact Styles | Pin / Socket |
| Crimp | x |
| Solder | x |
| Printed Circuit Solder | x |
| Printed Circuit Press Fit | |
| Thermocouple | x |
| Wire Wrap | |
| Co-ax | x |
| Insulation Displacement or Screw | |
| Pre-Terminated | |
| Fiber Optic | |
| High Voltage | x |
| First-Mate Last-Break |
